The LRU Page Replacement Policy

---

• In the Least Recently Used (LRU) page replacement policy, the page that is used least recently will be replaced.

• Implementation:
  • Add a register to every page frame - contain the last time that the page in that frame was accessed

  • Use a "logical clock" that advance by 1 tick each time a memory reference is made.

  • Each time a page is referenced, update its register

• The following figure shows the behavior of the program in paging using the LRU page replacement policy:



  • We can see notably that the bad replacement decisions made by FIFO is not present in LRU.

  • There are a total of 9 page read operations to satisfy the total of 18 page requests - that is almost a 20% improvement over FIFO in such a short experiment

  • (I only want to make the point here that page replacement policy can affect the system performance. I do not want to get into the question of "how much better is LRU than FIFO").

• In fact, it has been shown empirically that LRU is the preferred page replacement policy

• Disadvantage of LRU replacement policy:
  • To identify the page to replace, you need to find the minimum time stamp value in all the registers...

    Lots of work...

• There is a more efficient scheme that approximate the behavior of LRU that runs more efficiently...

  That method is "second chance" - next.
