Programming Example: tax computation

---

• Introduction

  • In this webpage, we will study a programming example using the conditional statements (if and if-else) to write a Java program to compute the tax owed.

  ---

  ---

• Formula to compute the tax owed
  • Decision diagram to compute taxes owed:

    ---

  • Example 1: someone single earning $40,000 pays:

    15% of $21,450,    plus 28% of ($40,000 − $21,450)

    Graphically:

    ---

  • Example 2: someone single earning $60,000 pays:

    15% of $21,450,                         plus 28% of ($51,900 - $21,450),      plus         31% of ($60,000 - $51,900)

    Graphically:

    ---

  • Algorithm:

    Define the following constants:

    S1 = 21450 S2 = 30450 M1 = 35800 M2 = 86500

    Structure diagram:

    ---

  • Example input: status = 'S' and income = 40000

    ---

    ---

  • The tax computation algorithm in Java:

    (The whole program is too large to show here).

    if ( status == 'S' ) { // ***** single if ( income <= S1 ) tax = RATE1 * income; else if ( income <= S2 ) tax = RATE1 * S1 + RATE2 * (income - S1); else tax = RATE1 * S1 + RATE2 * (S2 - S1) + RATE3 * (income - S2); } else { // ***** married if ( income <= M1 ) tax = RATE1 * income; else if ( income <= M2 ) tax = RATE1 * M1 + RATE2 * (income - M1); else tax = RATE1 * M1 + RATE2 * (M2 - M1) + RATE3 * (income - M2); }

  • Constants used in the program:

    RATE1 = 0.15          (Tax rate)             RATE2 = 0.28 RATE3 = 0.31 S1 = 21450           (Income brackets) S2 = 51900 M1 = 35800 M2 = 86500

    ---

  • Java program:

    import java.util.Scanner; public class ComputeTax { public static void main(String[] args) { final double RATE1 = 0.15; // Tax rates final double RATE2 = 0.25; final double RATE3 = 0.31; final double S1 = 21450.0; // Tax brackets for single final double S2 = 51900.0; final double M1 = 35800.0; // Tax brackets for married final double M2 = 86500.0; char status; double income = 0; double tax = 0; Scanner in = new Scanner(System.in); // Construct Scanner object System.out.print("Enter status (S or M) = "); status = in.next().charAt(0); // Read in status System.out.print("Enter income = "); income = in.nextDouble(); // Read in income >>>> Insert the Tax Computation Algorithm (see above) here <<<< System.out.println("Tax = " + tax); } }

    Programming advice:

    Using symbolic constants in computer program is highly recommended because when the tax rates or income brackets changes, we can easily accommodate the changes by changing the values of the constant definitions at the start of the program. We don't have to search for the constants inside the program !

    ---

  • Example Program: (The entire program is here)
    • Prog file: click here

    How to run the program:

    Right click on link and save in a scratch directory To compile:   javac ComputeTax.java To run:          java ComputeTax
